Why Do Different Musical Instruments Make Different Sounds?

Music is an essential part of our lives; for some it is a form of entertainment, and for others, it is a beloved escape. It is and has been an integral aspect not only of individual cultures, but entire nations and humanity as a whole. We have used music to organize our society, celebrate our festivals, express love and prepare for war, among many other things.

Over the years, we have seen an evolution of music and its various genres, driven by artists who release a single or an album of songs.

A song is produced by mixing different instruments and vocals together, creating new sounds from it. However, have you ever wondered why every instrument sounds so different? Why does a drum sound hard and deep, but a flute sounds so fluid and airy? Why does a piano sound mellow, compared to an electric guitar with its gritty, grungy sound?

Different ethnic music instruments. Save culture. Ethnic world. National instruments. - Image(Anna_Kuzmina)s

What gives instruments their unique sounds? (Photo Credit : Anna_Kuzmina/Shutterstock)

To understand why different instruments make different sounds, we will first have to understand the physics of music.

What is sound?

Sound is a wave that is created when an object vibrates. The vibration of the object is transferred through the displacement of the particles in the particular medium. When we hear something, the sound wave is transferred from the vibrating object and strikes our eardrum, which is then processed by our brain as the perception of sound.

Sound waves traveling in the air, hitting the eardrum

The quality of the sound that is heard depends on the physical properties of the sound wave. These physical properties are characterized as follows:

Wavelength

A wave travels in intervals of corresponding crests and troughs. A wavelength is considered to be the completion of one cycle of such a crest and trough.

Transverse Wave Infographic Diagram showing structure with displacement and propagation axis with all parts(udaix)s

Wavelength (Photo Credit : udaix/Shutterstock)

The thing to note here is that the particles themselves don’t travel through the medium, but rather displace the adjacent particle; this is how a wave travels. Similar to the wave formed when a loose rope is jerked, the strings of rope don’t travel, but they displace the adjacent particles, forming a wave by essentially making a back-and-forth movement.

Back-and-forth movement of the wave.

Frequency

The number of times waves go back and forth in a second is the frequency of that sound. Thus, Frequency = Complete cycles of waves / Unit of time. Its unit of measurement is Hertz, meaning that a frequency of 1 Hz is equal to 1 back-and-forth movement in 1 second.

The frequency of the sound determines its pitch, which is how high or low the sound is. A greater frequency, higher pitch sound would be nails-screeching on a chalkboard. A lesser frequency, low-pitched sound would be a deep bass drum.

The human ear detects a limited amount of frequencies. On the lower end, the deepest we can hear is 20 Hz and on the higher end, we can hear up to about 20000 Hz.

Amplitude

Amplitude is the height of the wave. The height determines the loudness of a sound. A higher amplitude results in a louder sound. The center of the wave is thought of as the resting position of the wave. The amplitude measurement is done from the center to the top and bottom ends of the crest and trough, respectively.

Notes

You have likely seen the keys of a piano at some point in your life. Each key corresponds to a note. The keys are arranged in pairs of 7 white keys and 5 black keys. Each key makes a unique sound because the sound coming from it vibrates on a particular frequency. The twelve keys are arranged from C to A. Together, each set of 12 is called an octave.

set of different sheet music symbols with piano keyboard - Vector(Toponium)s

Notes and octaves in a piano. (Photo Credit : Toponium/Shutterstock)

C1 vibrates at 32.70 Hz and A1 vibrates at 55.00 Hz. These notes are arranged in the ascending order of their frequency. So, C1 to A1 becomes an octave. These octaves keep ascending in order too, C2 to A2, C3 to A3 and so on.

These musical notations are universal to every instrument. The A4 played on the piano is the same frequency as the A4 played on the guitar. However, if that’s true, why do they make different sounds?

What gives instruments their particular sound?

Overtones and Harmonics

The proposition seems intuitive, that a note carrying the same frequency should sound the same on every instrument, but there is much more happening behind the scenes.

When we pluck the string of a guitar on the A3 note (110 Hz), the sound we hear is not made of just one frequency. The sound contains hidden frequencies underneath the base frequency (A3).

Multiple layers of waves in a sound, each of which is unique to the instrument.

So the string vibrates once at 110 Hz, it vibrates twice at 220 Hz and three times at 330 Hz. This is happening simultaneously, so all of them add up together to give the guitar its unique sound.

Strings make complex waves

These steps of frequencies are overtones, so 220 Hz becomes the 1st overtone and 330 Hz becomes the 2nd overtone. This can happen infinitely. The movement of the string becomes very complex when observed in reality due to this interaction of waves. We are unable to differentiate between the many overtones since it appears to be one sound, even though it is actually the sum of so many.

Vibration modes (frequency, Resonance, Harmonics) - Vector( Fouad A. Saad)s

(Photo Credit : Fouad A. Saad/Shutterstock)

Although we hear many frequencies together, in all, the string vibrates only 110 times per second. This happens because in the time the fundamental frequency completes one full cycle, the 1st overtone completes two cycles and the third completes three cycles. Thus, the entire pattern vibrates at the fundamental frequency of 110 Hz, which is made more complex by the added frequencies.

The additional frequencies are integers of the fundamental frequency. These integers are called Harmonics. In a harmonic series, the next frequency is always a multiple of the fundamental frequency. If the base frequency were 110 Hz, the next would be (2×110 = 220), (3×110 = 330) and so on.

Harmonics overtones fundamental - Vector(Fouad A. Saad)s

Harmonics – Integers of the fundamental frequency. (Photo Credit : Fouad A. Saad/Shutterstock)

Overtones correspond to harmonics, but at times overtones are not integers of the fundamental frequency, which is where both the terms depart from each other.

Overtones and Harmonics are one of the reasons why a guitar sounds different than the piano because they have strings of different lengths producing different frequencies.

Timbre

Our ears are very good at perceiving different sounds. One way it does this is through the “timbre” of the sound. Timbre is the tonal quality or the tonal color of the sound. The timbre of the sound is determined by the overtones and harmonics the sound makes.

Education Chart of different Sound Timbre Diagram. Vector illustration. - Vector(Vecton)S

The different timbre of different instruments. (Photo Credit : Vecton/Shutterstock)

The amplitude and pitch change in each harmonic gives instruments their particular timbre. This ‘quality’ of the sound is as much a perceptive phenomenon as a physical one. People can differentiate between two sound sources due to the perceptive capabilities of the ear.

The physical characteristics of the sound that determine its timbre are spectrum and envelope. A spectrogram displays the various frequencies of a sound in a visual form. The envelope describes how a sound changes over time, in both amplitude and pitch.

Spectrogram showing the ‘color’ of the sound

Material

The material of instruments is also one of the major reasons for their differentiated sounds, as the material directly affects the timbre of an instrument.

Different materials also have different densities, which affect the speed of the sound. Some materials are very reflective, which adds more layers to a sound.

Speed of Sound in Different Materials - Vector(Fouad A. Saad)s

Speed of sound in different materials (Photo Credit : Fouad A. Saad/Shutterstock)

The vibrations of materials are also a factor to consider. Metal vibrates differently than plastic, giving richer and crisper sound.

In Conclusion

Sound is one of the fundamental forces of nature, one that is an important part of the human experience. The differentiation of different sounds has helped us survive, by allowing us to communicate with each other in moments of danger. It has also helped us connect with others by helping us express the intangible.

Overtones, harmonics, timbre, and materials differentiate sounds and give instruments their unique quality. Thank God for that! How bland would this world be if every instrument sounded the same?
