Why Do Some Aircraft Have Wings Above The Fuselage, While Others Are Below It?

Table of Contents (click to expand)

Both high and low wing configurations present advantages and disadvantages to an aircraft’s flight, landing and servicing characteristics.

Even if one isn’t an aviation enthusiast, it’s quite difficult to miss the sheer grandeur of an aircraft. Upon close inspection, one may even point to the subtle differences between various craft.

However, did you know that while some aircraft have their wings near the bottom of the fuselage, some have them above it? Time to learn more!

Recommended Video for you:

Why Do Some Aircraft Have Wings Below The Fuselage, While Others Have Wings Above It?

Before we proceed, you should take a careful look at the following examples of aircraft. The fuselage is the tube-like section that houses passengers, crew, and luggage.

Can you spot the difference in the two aircraft
Can you spot the difference in the two aircraft? (Photo Credit : – sirtravelalot &  Jose Luis Stephens/Shutterstock)

In the first image, the wings originate near the bottom of the fuselage. Such aircraft are called low-wing aircraft. In contrast, the second image shows the wings extending from its top. These aircraft are called high-wing aircraft.

The placement of wings in an aircraft is a crucial aspect of its design, as they play many roles that include:

  1. Generating lift for flight
  2. Mounting engines and control surfaces for aircraft control
  3. Storing fuel
  4. Acting as a structural component for weight and impact distribution
  5. Being a part of the crash structure in the event of emergency landings.

Aircraft have various wing configurations, depending on their applications. However, we shall focus specifically on cantilevered wings, which are the face of modern general aviation (commercial, military and civilian).

Aircraft consist of a wing box that supports the wing and the weight of the aircraft in flight at the fuselage (Photo Credit : -frank_peters/Shutterstock)

A cantilever refers to any horizontally projecting structure supported only on one side. To ensure that they don’t collapse, cantilevered structures must be additionally reinforced when compared to loads supported on both ends. Cantilevered aircraft wings support their weight using a wing box that connects them to the fuselage.

Also Read: Why Are Aircraft Wings Curved At The End?

Low-wing Aircraft

A low-wing configuration is derived from wings attaching to the lower part of the fuselage. This causes the wing box to take up usable space in the fuselage. This restricts its use to carrying passengers and light cargo only.

The upward incline of low wing aircraft is called dihedral
The upward incline of low-wing aircraft is called dihedral (Photo Credit : Adrian Pingstone & Kerina yin//Wikimedia Commons)

The wings do not protrude straight out of the fuselage; they are instead inclined upwards. This is known as dihedral, and is essential to an aircraft’s flight.

It imparts stability during turning (known as “roll” in aviation parlance), preventing it from staying its course or dropping altitude in the middle of the turn (known as side-slip).

Ground effect causes an aircraft to float on an air cushion contained between its wings and the ground, preventing it from landing, as demonstrated by the unmanned aerial aircraft here. (Photo Credit : Skimmerfoil1/Wikimedia Commons)

Low-wing aircraft are less susceptible to drag, but can incur a high ground effect upon landing. Occurring due to air between the wing and the ground, ground effect causes the aircraft to float, preventing it from landing. Low-wing aircraft are better suited to land on paved surfaces, as critical components are close to the ground.

Low-wing design offers great forward and upward visibility. Unless the aircraft is in a roll, the wings can obstruct a pilot’s view of the ground, and consequently, approaching air traffic.

High-wing Aircraft

When wings attach directly to the top of the fuselage, a high-wing configuration is achieved. As the wing box is out of way, this setup makes it ideal for freighters and cargo aircraft.

As the aircraft’s body is located ‘under’, the wings, its center of weight tends to bring it back to an upright position, much like a pendulum. While this imparts a lot of stability for rolling maneuvers, it fundamentally resists any rolling. This requires other control surfaces, such as ailerons, to help turn the aircraft. To help with this, the wings are inclined downwards, or in an anhedral position.

The downward incline of aircraft wings is also called anhedral (Photo Credit : -kamilpetran/Shutterstock)

High-wing aircraft are aerodynamically more susceptible to drag, but experience less ground effect. They are more forgiving on rough terrain, as wings and engines are sufficiently cleared upon touch down. High-wing aircraft offer great downward visibility, as the wings do not obstruct the pilot’s view. However, such aircraft can be compromised during roll.

Also Read: How Do Fighter Jets Fly Upside Down?

Does Wing Configuration Really Matter?

Short answer – No! Both formats of wings have their pros and cons. However, this doesn’t make one aircraft less conducive to flying than the other. The choice of wings is purely dependent on the aircraft’s intended purpose, and no one design presents inherent superiority over the other.

Other Wing Configurations

It is worth noting that aircraft are not restricted to high- or low-wing configurations. Some of these configurations are enumerated below, but they don’t find widespread use in general commercial or military aviation, owing to their design shortcomings.

1. Fused-wing Configuration

A fused-wing configuration, also known as a blended wide body, is a unique aircraft design. In this, the fuselage itself converges to form wings, as opposed to distinct wings that ‘attach’ to it.

The B-2 Bomber is a popular and perhaps the only functional blended-wing design aircraft today (Photo Credit : -Eugene Berman/Shutterstock)

Its shape allows the entire aircraft to generate lift, as opposed to restricting this responsibility only to the wings. Its downside is severe space constraints. One of the most popular examples of fused-wing configuration aircraft is the B2 stealth bomber in the United States Air Force. They are also becoming increasingly popular in unmanned aerial vehicle design.

2. Mid-wing Configuration

As the name suggests, such configurations are achieved when the wings are mounted in the middle of the fuselage. This causes the wing box to occupy prime space within the aircraft, making it unsuitable for passengers or cargo.

To create space for passengers, the wings of mid-wing aircraft can be pushed aft of the fuselage (Photo Credit : Eddie Maloney/Wikimedia Commons)

Mid-wing configuration aircraft find use in acrobatic, private and combat aircraft.

3. Tandem-wing Configuration

Tandem-wing aircraft comprise both high- and low-wing configurations arranged in a staggered pattern, one behind the other.

Tandem-wing aircraft enjoy the best of both worlds (Photo Credit : -Flying Camera/Shutterstock)

They demonstrate exceptional stability and are even purported to reduce wing span. They are being increasingly used in unmanned aerial vehicles and other light aircraft.

4. Braced Wings

Unlike all the formats mentioned above, braced wings are the most unique, in that they are not cantilevered. Instead of wing boxes; they rely on pylons, struts and cables to support their structure.

Braced wings, unlike cantilever wings, are supported by struts and pylons (Photo Credit : -twintyre/Shutterstock)

They are neither aerodynamically nor structurally as sound as cantilever wings, which reduces their application to light recreational aircraft, such as gliders.

A Final Word

Wing design is greatly impacted by aerodynamics and the machinery mounted on them. Electrification of aviation is surely the next big change in the aviation industry. As to how this will impact wing design… only time will tell!
