What Is Echolocation?

Ben Underwood has been unfortunately blinded by cancer since the age of two. However, if you were to visit his California neighborhood, you would often find him cycling on the streets. Quite popularly recognized as ‘The Boy Who Sees Without Eyes’, he can discern people, cars and the next turn in his course.

If he were to ride past you, you would hear – other than his bell’s peal – a series of sharp “clicking noises” made by him. The high-frequency noises emanated from him return to him after they reflect and ricochet off nearby objects. He then uses these echoes to map or ‘see’ his surroundings. This real-life Daredevil has developed and honed a sense of vision that animals sequestered in darkness have mastered over millions of years. The process is appropriately termed echolocation.

Advertisement

Echolocation Definition

Echolocation is a physiological process that acts like an “auditory imaging system” that works on the same principle of emitting high-frequency sound waves which are reflected back to the emitter. These reflected sound waves are analyzed by the brain to gain information about its surroundings. This might also help marine animals to develop 3D images of their surroundings.

Echolocation in animals

Bat Echolocation

The term was coined by the zoologist Donald Griffin, who was the first animal behaviorist to demonstrate with conviction how bats exercised it regularly. Even though bats possess eyesight, it is futile in the remote corners of dark caves. Such an unlit location, which they so often find themselves in, effectively renders them blind.

In these circumstances, bats, just like Ben, use sound to ‘see’. However, while Ben uses high-frequency sound waves to discern obstructions, bats use ultrahigh-frequency sound waves to achieve the same. Sound waves of such exorbitant frequencies cannot be detected by human ears because they lie outside of our hearing range (20 Hz to 20 kHz).

bats in cave

While a few bats are known to radiate the pulses through their nose, most bats tend to vocalize them. The frequency is measured to be around 200 pulses per second, however, the period can vary with the species of a bat. Credits: Adi Ciurea/Shutterstock

A bat’s squeaks are more lucrative than Ben’s because with higher frequency comes higher resolution or more vivid detail – they are capable of avoiding obstacles no wider than a human hair! They use it to locate and navigate towards prey, such as a scampering insect.

Advertisement

As the detected sound waves that form the images are essentially echoes, they must conform to a rule — the retrieved train of pulses must be loud enough to return to the sender, but short enough such that the echo of the sender returns before the next one departs.

Marine mammals

Whale Echolocation

Another species of animals that evolved this brilliant ability are marine mammals. The Sun’s edged light cannot pierce all the way through to the solitary depths of the ocean. These dwellings, devoid of any light, like obscure, voluminous caves, are dark and solemn. The inhabitants, such as whales, overcome this blindness by using echolocation.

Whale

Whales implement echolocation by emitting a series of high-frequency clicks. Credits: Catmando/Shutterstock

The sounds generated by whales are often termed as ‘songs’. They use these songs not only for navigation and food but also for long-range contact and to warn others for possible threats. In terms of catching prey, whales emit a trail of clicks towards it. As they prowl forward, the frequency of clicks increases. In the prey’s proximity, it grows so great that together these clicks can be heard like a consistent buzz.

Dolphin Echolocation

Dolphins rely on echolocation even when the light would suffice. They evolved the trait because their eyesight is not particularly great. Fostering this trait has a fortuitous effect – sound waves travel faster in water than light waves do. Dolphins generate the high-frequency pulses by squeezing air through nasal passages located beneath their blowholes. They then focus on these waves with a fat-filled area covered by the forehead known as the melon. The melon focuses its sound waves like lenses converge waves of light. Finally, the reflected waves are detected by the dolphin’s lower jaw and forehead. These areas have cavities filled with fatty tissues. They direct the sound waves towards the ears. They transform it into signals which are sent to the brain for interpretation.

dolphins

A group of dolphins emerging from the surface to draw breath. (Photo Credit: vannino / Pixabay)

The combination of visual data and echolocation helps them determine the shape, speed, distance and even some basic facts about the internal structure of the objects in the water! This helps them to find food and swim in murky water.

Echolocation in humans

The ability to build tools, a trait that largely explains our triumph over other species, has enabled us to outsmart nature and overcome our weaknesses. The upgrades or extensions are often inspired by what we covet among the myriad talents we find in nature’s circus — the ability to fly, move faster, apply crushing strength and — after studying echolocation — develop stealth technologies.

Submarines employ a technique known as Sound Navigation And Ranging (SONAR) to monitor enemies or animals underwater from a distance without making their presence felt. Echolocation inspired a variant of SONAR called active SONAR, where submarines listen to the reflections of sounds transmitted towards a target by the submarine itself. The other variant is passive SONAR, where a submarine triangulates by listening to sounds made by the surveilled object. This is what Batman used to track the Joker in The Dark Knight.

Batman implemented passive SONAR to draw a map of Gotham by listening to every cell phone in Gotham. This allowed Batman to track the location of the Joker when someone used a phone in his proximity.

However, while our physiology completely prohibits us from flying, the same cannot be said of echo-locating. Ben Underwood is a shining example of our mysterious, suppressed ability to guide ourselves with sound waves. It was Aristotle who first introduced the notion of the five senses. These senses, he believed, were separate, independent of each other. However, modern neurology would vehemently disagree.

Neurologists discovered that the neuronal wires associated with these senses are installed like a tremendously condensed clump of trees. They cannot help but influence the operation of other senses. This is why the pungent smell of your food can exacerbate its taste.

What’s more, when a tree ceases to grow, the other trees presumptuously grow and spread over it. Due to the plasticity of the brain, the depreciation of one sense causes the heightening of another. The wires of touch, smell and hearing that colonize the defunct wires of vision in the brain of a blind person facilitate the heightening of his or her tactile, olfactory and auditory sensitivities.

Daredevil

Daredevil relies on echolocation to vanquish his enemies. (Photo Credit: Daredevil / Marvel Television)

However, the enhancement in acuity is not what you would traditionally expect; blindness doesn’t simply make you a more acute listener. Studies have shown that blind people score equally on hearing tests as people with vision do. Surprisingly, echoes don’t stimulate a blind person’s auditory cortex; instead, they activate his or her visual cortex. This stimulation is what enables Ben to ‘see’ his surroundings.

The diffusion of wires makes you more conscious of the deep synchrony or interdependence of senses you thought you never possessed. In fact, one doesn’t even have to be blind to achieve this; with deliberate practice, you can train yourself to see with your ears like a bat or dolphin!

The early work of psychologist Karl Dallenbach on ‘facial vision’ found that blind people could detect the presence of a board placed in their path as they walked towards it. More incredible, however, is the finding that even sighted people who were blindfolded demonstrated this after just 30 trials! The researchers suspected that the sighted subjects were seeing just how the blind subjects were — by implementing active SONAR. To test this, they placed the objects on carpets, inside thick socks. Both subjects suffered from exactly what you would imagine – a loss of “vision”. This ‘sixth sense’ is yet to be studied in extensive detail, however, this startling finding has surely opened our eyes to newer, unforeseen avenues (see what I did there?).

References

  1. University of Hawaii
  2. Public Library of Science
  3. Arizona State University
  4. Department of the Environment and Energy, Australian Government
