How Did Houses Cool Before ‘Air Conditioning’ Became A Thing?

Listen to this post
Voiced by Amazon Polly

Before the advent of artificial air conditioning, people used many different ways to cool their houses. Some of these techniques included designing houses with respect to the surrounding environment, using evaporative cooling, wind-catchers, etc.

Summers can become an unbearable mess sometimes. Rising temperatures in the afternoon, sun beating down on top of your head, roads filled with traffic and pollution… it all feels like a bad and very sweaty drag.

Fortunately, we now have the option of cushioning ourselves in an enclosed room with the temperature turned way down on the AC unit, effectively detaching ourselves from the heatwave going on outside.

This, of course, wasn’t always an option. The first air conditioning systems were powered back in 1902, meaning that artificial cooling is a relatively new phenomenon. Just imagine how miserable it would have been for folks in the scorching summer when their only option would be to vigorously wave a paper fan with their hands.

Fortunately, they had more options then handheld fans, as people found plenty of natural methods to keep their houses cooler than the temperature outside. They employed methods of passive cooling to design houses in a way that is in accordance with the climate, enabling them to lower the temperature inside the house.

Let’s look at some of the ways people naturally cooled their homes.

Ways in which houses were cooled naturally

Without modern technology, people relied heavily on the way houses were built in accordance with the local climate to maximize heat dissipation and thermal insulation. Many buildings constructed today completely disregard this, as it is easy to simply build a box and slap electric air conditioning on the side. In the past, people did not have this option, so they had to learn techniques to make houses as site-friendly and aligned with the climate as possible, making it completely natural. These tricks were used to make their houses cooler:

House layout based on the climate of the site

As stated before, the climate of a site is one of the most important aspects of deciding how a building should be constructed. This must be done by taking into account the movement of the sun and wind on the site. The information that this provides determines the location of the rooms in the houses, so placing rooms in the opposite direction of the sun’s path would make the room naturally cooler than the others.

Wind direction also plays an important role, as the flow of natural wind in a room would help keep it ventilated and cooler. Some very interesting examples include Indian step wells, which were dug underground in the shape of stairs. The level underneath has water and as is away from sunlight, making it much cooler than the rooms above.

Adalaj, Gujrat, India- November 16,2010 The beautiful Step well of Adalaj ( Adalaj or Rudabai stepwell or baoli ) Near Ahmadabad - Image( Abhijeet Khedgikar)s

Stepwells make the room on the lower floors cooler. (Photo Credit : Abhijeet Khedgikar/ Shutterstock)

Shading of the house

Well-designed exterior shading of the house cuts off the harsh sunlight coming in during the afternoon. This reduces the heat gain on the exterior surfaces of the house (windows and blank walls) and also ensures ambient temperatures in semi-open and outdoor areas of the house.

Initially, this shading was done with trees, but as techniques evolved, the shading could be achieved by an opaque slab running through the house (seen above modern windows), extended balconies, and perforated wooden shades called pergolas. Examples of this are seen in Mughal architecture with jharokhas, which provide a separation of space, reducing the temperature of the room inside.

Maheshwar Fort

Jarokha’s help shade rooms from the penetrating sunlight. (Photo Credit : Bernard Gagnon/Wikimedia Commons)

Thermal insulation

The thickness of the walls and the roof of the house plays an important role in transferring heat from the exterior to the interior. Many materials are used to insulate this transfer, making the interior rooms much cooler. These materials are stacked between the walls; some of the common ones are wool, cellulose fiber and glass fiber.

Thermal insulation boards are drilled on the back of the roof to avoid heat transfer. Earth walls help a lot in insulating the houses, as it is a cooler material; adding splashes to the walls makes the incoming air cool and pleasant.

Plastic (mansard) or skylight window on attic with environmentally friendly and energy efficient thermal insulation rockwool. - Image(brizmaker)S

Thermal insulation on roofs to reduce heat gain. (Photo Credit : brizmaker/ Shutterstock)

Natural Ventilation

Keeping windows facing the direction of the wind helps cool down rooms with the breeze. Having two windows on two opposite walls or having a courtyard on one side helps this even further, as there is a constant flow of wind in the room, giving no time for the hot air to linger.

Innovative window-making techniques also help get rid of warm air. As warm air moves higher than cooler air, small vents were placed on the windows for its elimination, thus making the room cooler. Black openings are also placed on the roof for the suctioning of warm air, with a wind tunnel on the ground to cool the incoming air.

Earthship-ventilation-cooling-tube-schematic copy

Earth walls with openings for airflow (Photo Credit : Bernard Gagnon/Wikimedia Commons)

Windcatcher

In use for thousands of years, a windcatcher is a small tower with an opening on the top. The tower ‘catches’ the wind flowing above and forces it to enter the houses, thus cooling the interior. This is the simplest type of windcatcher.

Edificios en Yazd, Irán

Windcatcher (Photo Credit : Diego Delso/Wikimedia Commons)

Another type is used with a qanat, which is the opposite of the one described above. A qanat is an underground tunnel with a water body for the warm air to cool down. The air then flows into the room and goes out of the opening on top of the tower, thus completing the ventilation cycle.

Windcatcher with qanat (Photo Credit : Samuel Bailey/Wikimedia Commons)

Evaporative Cooling

Our bodies cool through evaporation. As we exert energy and perspire (sweat), the evaporation cools our body down. This same principle is used in making a room cooler through evaporation. Wet khas-mats hung on a window on a windy day will make the room cooler inside. This method is so effective, in fact, that modern coolers use the same principles to operate. The earliest example of this is the Egyptians using wet reeds on their windows to cool down their rooms.

Cattail and reed plant isolated on white background. Wild grass - Image(Artiste2d3d)s

Egyptians used wet reeds for evaporative cooling (Photo Credit : Artiste2d3d/ Shutterstock)

Aqueducts

Romans gave us many engineering marvels and aqueducts are one of them. Aqueducts are an underground network linked to a water supply and used to connect clear sources of water to community spaces and individual houses. They were also used to take heat away from houses by pumping into the walls. However, this was just for the elite, as it was an expensive system to develop and use. These aqueducts were also used to fill Roman fountains, which were used to cool down the common public.

Pont du Gard three-tiered aqueduct was built in Roman times on the river Gardon. Provence summer day. - Image(cge2010)S

Three-tier aqueduct (Photo Credit : cge2010/ Shutterstock)

Conclusion

We’ve come a long way, from sprinkling water on our walls to installing electric air conditioners without a second thought. People have always found ingenious ways to get some relief in the heat and identified ways to create a balance with the local environment. As artificial air conditioning is not very environmentally friendly, we can still use some of these clever approaches when designing new buildings to reduce the need for artificial cooling!

References

  1. Pennsylvania State University (Link 1)
  2. The Ohio State University
  3. Massachusetts Institute of Technology
  4. Pennsylvania State University (Link 2)
