How Do Fire Sprinklers Work?

Fire sprinklers activate when high temperatures pop their bulbs. They don’t go off easily and cause havoc, although movies would have us believe that!

Hollywood has always used fire sprinklers as a useful trick to resolve a scene. Sprinklers go off “accidentally” or are cleverly “turned on” by our heroes. This strategy may be used for an action sequence or comedic relief, or even to serve as a romantic backdrop for an indoor kiss in the rain.

However, did you know that most movies get fire sprinklers woefully wrong? The truth is, sprinklers don’t quite work the way that movies want us to believe. Consider the scene in Bridget Jones’s Baby, where a birthday cake sets off the entire fire sprinkler system. It’s quite impossible for that to happen.

So how do fire sprinklers work? How do they go off at just the right moment of a fire, and can they really be set off accidentally?

Overview of Automatic Fire Sprinkler Systems

A sprinkler fire fighting system automatically detects and extinguishes fires inside an indoor space. It’s one of the different forms of active protection against fire. The major advantage of this is that it works completely automatically, with no need for manual intervention.

The first automatic fire sprinklers date back to London in 1812. Although there have been significant changes in design, the basic principles used in the system remain much the same.

AUTOMATIC SPRINKLER SYSTEMS EXISTED mee

Automatic fire sprinkler systems are extremely effective. Stats show that in the UK, there has never been a death in a building with a sprinkler set up, unless an explosion was involved. Worldwide stats only show 50 deaths in sprinklered premises.

The system consists of a water supply and a network of pipes leading to sprinkler heads as the most basic elements. A fire pump is used to pump the water into the pipes from the water source. The pipes are kept pressurized to ensure that the water flowing out will be forceful enough to extinguish a fire.

In laboratories and warehouses, you may see a sprinkler network installed under the ceiling. In buildings like shopping malls, the pipes may be laid over a false ceiling, with only the sprinkler heads visible below. In most cases, we may only see the little heads poking out.

Fire,Sprinkler,System,With,Red,Pipes,Is,Placed,To,Hanging

Fire sprinkler network inside a building. (Photo Credit : NavinTar/Shutterstock)

The sprinkler heads, and the glass bulbs within them, are the triggers in the system.

How do fire sprinklers go off?

Aside from the pressurized water in the pipes, how do the sprinklers actually go off? Fire sprinklers, specifically sprinkler heads, are able to detect heat.

This is what a sprinkler head looks like:

old-fire-sprinkler-close-up_t20_3QGPmo

A fire sprinkler head. (Photo Credit : twenty20)

The red vial-looking thing in the middle is the glass bulb. This is the key element for the operation of a sprinkler head. The opening in the sprinkler head is kept closed by this glass bulb. It’s usually filled with glycerin-based liquid that is sensitive to temperature.

When there’s a fire, the air around it heats up. The hot air travels upward, to where the sprinkler head is located. This causes the liquid inside the bulb to heat up and expand. When the temperature of the glass bulb reaches a threshold limit, the liquid expands beyond what the glass can contain, and it breaks!

The bulb breaking causes the sprinkler heads to ‘open’ and trigger the system. The difference in pressure caused by the broken bulb causes valves to open and the water to rush out of the nozzle, and spray over the fire. In most cases, an alarm is also set to trigger when this system is tripped.

Water Splashing out of Water Sprinkler

Sprinkler Operation. (Photo Credit : Elmer Laahne PHOTOGRAPHY/Shutterstock)

Different sprinkler installations may have different threshold temperatures. This depends on factors like the normal room temperature of the protected space, which depends on the location, the purpose of the protected space, and the maximum temperature that you can expect the room to be without a fire present that needs to be put out. The range usually falls between 57-74 degrees Celsius. The color of the liquid inside the bulb usually indicates its threshold temperature.

The most common temperature ranges come in orange, red, and yellow ones. For instance, for Viking standard response sprinklers, the lowest-rated bulbs are orange with a temperature rating of 57˚C, then red at 68˚C, and yellow at 79˚C. The highest-rated ones are black with a temperature rating of 260˚C and are only used in special circumstances.

Temperature Color Temperature Rating Max. Ceiling Temperature
57˚C Orange Ordinary 38˚C
68˚C Red Ordinary 38˚C
79˚C Yellow Intermediate 65˚C
93 or 100˚C Green Intermediate 65˚C
141˚C Blue High 107˚C
182˚C Mauve Extra High 149˚C
260˚C Black Ultra High 240˚C

Types of Automatic Fire Sprinkler Systems

The most commonly used system is a wet pipe-type sprinkler system. In this setup, the pipes are kept filled with water and pressurized. This means that the water is always waiting just behind the sprinkler heads, resulting in very fast reaction times.

Dry pipe sprinkler systems are used in areas where water might freeze in the pipes, or in areas prone to natural calamities where there is a chance of the pipes rupturing. Here, the pipes are not filled with water, but rather with compressed air. When a sprinkler is activated, this pressurized air rushes out and the water from the source rushes in.

There are further variants of the dry pipe system. Pre-action systems rely on two triggers—one like a smoke detector or a manual trigger to allow water into the pipes, and then the usual bulb trigger to set the system off. This two-step system is used in places with water-sensitive equipment or artifacts inside the premises, for added protection against accidental triggers.

The last type is the deluge system, which is very rare in real life, but seems particularly widespread in movies. We’ll discuss that variety in more detail below.

Can fire sprinklers go off accidentally?

Let’s clear one thing up at the start… no burnt toast or candle-riddled birthday cake can set off a fire sprinkler. Only an actual fire with a “might-burn-down-the-house-if-left-unchecked” nature could possibly raise the temperature of the air enough to actually rupture the glass bulb of a sprinkler head.

The other misconceived image is that of the all-or-nothing sprinkler system. In actuality, the thing about the design of most sprinklers is that only the sprinkler heads that are near the fire will go off in the event of localized fires. Only the bulbs near enough to the fire to get sufficiently heated will break, so only those sprinkler heads will go off.

In most cases, fires start from a single point of origin, so fire sprinklers work pretty effectively at cutting off the fire before it reaches a point where the entire sprinkler network needs to be activated. In 90% of cases, one sprinkler succeeds in extinguishing the fire before the others are triggered.

In other words, it’s not like in the movies when the whole system turns into a waterfall at the tiniest hint of fire. Your office computer won’t get drenched because you started a fire in the break room.

Consider the scene in Veronica Mars, when Kristen Bell holds up a lighter to the smoke alarm and triggers all the sprinklers in the room instantaneously. This is quite an unlikely event, as realistically, only Veronica would have gotten soaked in such a situation.

Triggering a smoke alarm or a manual fire alarm trigger also won’t cause the system to go off in most cases. We see this misconception in countless movies where all you need to do is pull the emergency fire alarm lever and moments later… an indoor rainstorm!

Usually, fire sprinklers will be set off only if they encounter a sufficiently high temperature. The manual fire alarm may trigger other safety measures, but not a glass bulb sprinkler system.

Deluge Fire Sprinkler Systems

The type of sprinkler “overreaction” seen in movies is only possible in the case of a deluge sprinkler system.

The operation of a deluge sprinkler system.

The operation of a deluge sprinkler system. (Photo Credit : Flickr)

Deluge systems don’t have individual heat-sensitive glass bulb triggers on sprinkler heads. The sprinkler heads are always ‘open.’ They are triggered by some other alarm. Thus, when another trigger—a smoke alarm, a manual trigger, or some other alarm—is set off, they go off all at once, causing a “deluge”, as the name suggests.

But the thing is, deluge systems are actually really rare. Deluge sprinkler systems are only installed in places with extremely high fire risks, precisely because they go off so easily. As much as people might fear fires, nobody wants the risk of accidental water damage either!

fire-sprinkler-water-damage

Most movie scenes with sprinklers are not set in spaces where there would be any need for a deluge system to be set up. So we can conclude that movies are working with and leaning into some common misconceptions about fire sprinklers.

A Safe Bet

People might decide against installing automatic fire sprinkler systems in their homes or offices because they’re afraid that the sprinklers might go off accidentally. In actuality, the probability of accidental sprinkler discharge is 1 in 16 million. Sprinkler heads can only go off in the presence of a temperature as high as only a fire could produce, and only the sprinkler heads above the actual fire will go off.

In other words, an automatic fire sprinkler system is a very good system to choose if you’re looking for the most reliable protection against fires.
